Precise and smooth main drive
The one-piece headstock contains a mechanical gearbox with 16 geometrically stepped speeds. Hardened and ground gears ensure precise running and low noise levels.
Conventional Precision Lathes
COMEV MT Series
Classic mechanics, robust construction, and precise machining: The conventional COMEV lathes of the MT series are reliable machines for workshops, maintenance, tool making, and single-part production.
Proven Italian machine engineering quality
Four machine sizes
Consultation and service from Germany
200–260 mm
Center height
up to 2,000 mm
Center distance
52 / 62 mm
Spindle bore
4 models
MT Series
A classic quality machine
The lathe that should not be missing in any workshop
The COMEV MT combines the tradition of Italian machine tool construction with a durable design that has been consistently developed for daily use.
Whether used regularly in production or only for special repair and modification work: The machine is always ready for use and is particularly suitable for maintenance, tool making, training, as well as single-part and small series production.
High-quality mechanical components, a stable cast construction, and direct operation via handwheels and control levers make the MT series a reliable and well-controllable workshop machine.
Robust and clearly structured mechanics
For repair, training, and manufacturing
Long service life and easy maintenance
Direct processing without CNC programming
Conventional. Precise. Reliable.
Full control over the machining process and operation familiar to experienced turners.
Construction and technology
Designed for durability and precise operation
The MT series relies on proven mechanical assemblies, high-quality materials, and a robust construction.
Thermally stable spindle construction
The hardened and precision-ground main spindle runs in high-precision tapered roller bearings. Depending on the model, the spindle bore is 52 or 62 mm.
Wide range of feeds and threads
The enclosed, oil-bath-lubricated Norton gearbox provides numerous longitudinal and cross feeds as well as metric, Whitworth, module and diametral-pitch threads.
Stable yet sensitive to operate
The generously dimensioned carriage offers high rigidity during machining while remaining precise and sensitive to operate during manual infeed movements.
Solid foundation for precise machining
The wide machine bed and carefully matched guideways provide the foundation for high stability, dimensional accuracy and a long service life.
Robust and adjustable support
The one-piece tailstock features an adjustable base and a hardened and ground quill with Morse taper socket.
Machine details
Thoughtful operation down to the detail
The clear structure simplifies setting up, operating, and maintaining the machine.
Generous working area
Good access to the workpiece, toolholder and steady rests makes setup and machining easier.
Precise slide package
Mechanical handwheels and clearly arranged controls enable direct and controlled infeed movements.
Stiff tailstock
The robust tailstock provides reliable support for machining between centres and drilling operations.
Model overview
The right MT for your workshop
The series covers different workpiece diameters, turning lengths, as well as requirements for stability and performance.
MT 20
Compact version with a 200 mm centre height and 52 mm spindle bore.
MT 20P
Reinforced version with a wider machine bed and higher machine weight.
MT 22
220 mm centre height, 62 mm spindle bore and up to 2,000 mm distance between centres.
MT 26
Largest version with a 260 mm centre height and 520 mm swing over the bed.
| Technical data | MT 20 | MT 20P | MT 22 | MT 26 |
|---|---|---|---|---|
| Center height over bed | 200 mm | 200 mm | 220 mm | 260 mm |
| Center distance | 1,000 / 1,500 mm | 1,000 / 1,500 / 2,000 mm | 1,000 / 1,500 / 2,000 mm | 1,000 / 1,500 / 2,000 mm |
| Swing diameter over bed | 400 mm | 400 mm | 440 mm | 520 mm |
| Swing diameter over cross slide | 230 mm | 230 mm | 245 mm | 295 mm |
| Bed width | 260 mm | 320 mm | 320 mm | 320 mm |
| Spindle bore | 52 mm | 52 mm | 62 mm | 62 mm |
| Spindle mount | Camlock 6" | Camlock 6" | Camlock 6" | Camlock 6" |
| Number of spindle speeds | 16 | 16 | 16 | 16 |
| Speed range | 36–1,600 rpm | 36–1,600 rpm | 36–1,600 rpm | 36–1,600 rpm |
| Spindle motor | 4 kW | 4 kW | 5.5 kW | 5.5 kW |
| Tailstock mount | MT4 | MT4 | MT4 | MT4 |
| Quill diameter | 58 mm | 58 mm | 62 mm | 62 mm |
Technical specifications according to the manufacturer's documentation. Subject to technical changes, equipment variations and errors.
Standard equipment
Prepared for workshop use
The standard equipment already includes essential components for safe and versatile operation.
Camlock flange
Fixed steady rest
Follow steady rest
Fixed centering points
Reducing sleeve
Coolant lubrication system
Spindle protection
Slide protection
Rear splash guard
Operating documentation
Service tool
Machine light*
*Equipment may vary depending on machine version and quotation.
Typical application areas
Versatile use
Maintenance
Fast production and reworking of shafts, bushings, pins and custom spare parts.
Tool and fixture construction
Precision production of individual parts, workholding devices, mountings and auxiliary tools.
Training
A practical way to learn the fundamentals of turning and directly understand the relationship between infeed, feed rate and cutting action.
Single part production
Cost-effective machining of custom workpieces without the programming and setup effort of a CNC machine.
Repair workshops
Ideal for short-notice modifications, reworking and restoring existing components.
Small series production
Flexible production of small quantities with direct control over the entire machining process.
Nolte Sales & Nolte Engineering
More than just a machine tool
We support you from selecting the right machine size through commissioning and long-term technical support.
Our services
✓ Technical consulting and machine configuration
✓ Quotation and financing support
✓ Delivery and installation
✓ Commissioning and operator training
✓ Maintenance, repair and spare parts service
✓ Contact partner in Germany
Which COMEV MT fits your application?
Tell us the workpiece diameter, required turning length, material and intended application. We will advise you on selecting the appropriate machine version.
